GIGABYTE MU72-SU0 ATX Server Motherboard Socket P Intel C621A

Description Learn more about the GIGABYTE MU72-SU0 Best Seller Ranking #33 in Server Motherboards Model Brand GIGABYTE Model MU72-SU0 Supported CPU CPU Socket Type Socket P CPU Type Supports 3rd Gen Intel Xeon Scalable ProcessorsSupports Intel Xeon Platinum / Xeon Gold / Xeon Silver Processors Chipsets North Bridge Intel C621A Memory Number of DDR4 Slots 8 x 288-pin DDR4 Standard DDR4 3200 Maximum Memory Supported 256GB Expansion Slots PCI Express 4.0 x16 Slot_7: 1 x PCIe x16 (Gen4 x16 bus) slotSlot_6: 1 x PCIe x16 (Gen4 x16 or x8 bus) slot, shared with Slot_5Slot_5: 1 x PCIe x16 (Gen4 x0 or x8 bus) slotSlot_4: 1 x PCIe x16 (Gen4 x16 or x8 bus) slot, shared with Slot_3Slot_3: 1 x PCIe x16 (Gen4 x0 or x8 bus) slotSlot_2: 1 x PCIe x16 (Gen4 x16 or x8 bus) slot, shared with Slot_1Slot_1: 1 x PCIe x16 (Gen4 x0 or x8 bus) slot Storage Devices SATA RAID 0/1/10/5 M.2 1 x M.2 slot:– M-key– PCIe Gen3 x4 per slot– Supports NGFF-2280 cards SAS 3 x SlimSAS for 12 x SATA III 6Gb/s ports Onboard Video Onboard Video Chipset Onboard Video Chipset Aspeed AST2600 Onboard LAN LAN Chipset Intel I210-AT LAN Speed 10/100/1000Mbps Max LAN Speed 10/100/1000Mbps Rear Panel Ports Back I/O Ports 4 x USB 3.01 x VGA1 x COM2 x RJ451 x MLAN1 x ID button with LED Onboard Ports Other Connectors 1 x 24-pin ATX main power connector1 x 8-pin ATX 12V power connector1 x 6-pin ATX 12V power connector ( for PCIe slot)3 x SlimSAS connectors1 x M.2 slot1 x CPU fan header6 x System fan headers1 x USB 3.0 header1 x TPM header1 x VROC connector1 x Front panel header1 x Buzzer Dimensions Form Factor ATX Dimensions (W x L) 12″ x 10″ Packaging Package Contents 1 x MU72-SU01 x I/O shield1 x Quick start guide1 x SlimSAS for 4 x SATAIII 6Gb/s cable Additional Information Date First Available January 10, 2022 Customer Reviews of the GIGABYTE MU72-SU0 There are no reviews yet. Do you own this product? write a review
