GIGABYTE MD72-HB2 Extended ATX Server Motherboard Dual Socket P Intel C621A

Description Learn more about the GIGABYTE MD72-HB2 Best Seller Ranking #64 in Server Motherboards Model Brand GIGABYTE Model MD72-HB2 Supported CPU CPU Socket Type Dual Socket P CPU Type Supports 3rd Gen Intel Xeon Scalable ProcessorsSupports Intel Xeon Platinum / Intel Xeon Gold / Xeon Silver Processor Chipsets North Bridge Intel C621A Memory Number of DDR4 Slots 16 x 288-pin DDR4 Standard DDR4 3200 Maximum Memory Supported 256GB Expansion Slots PCI Express 4.0 x16 Slot_6: 1 x PCIe x16 (Gen4 x16 bus) slot, from CPU_0Slot_5: 1 x PCIe x16 (Gen4 x16 bus) slot, from CPU_1Slot_4: 1 x PCIe x16 (Gen4 x16 bus) slot, from CPU_1Slot_3: 1 x PCIe x16 (Gen4 x16 bus) slot, from CPU_0Slot_2: 1 x PCIe x16 (Gen4 x16 bus) slot, from CPU_0Slot_1: 1 x PCIe x16 (Gen4 x16 bus) slot, from CPU_1 Storage Devices SATA 2 x 7-pin SATA 6Gb/s ports SATA RAID 0/1/10/5 M.2 2 x M.2 slots:– M-key– PCIe Gen4 x4 per slot– Supports NGFF-22110/2280 cards– From CPU SAS 3 x SlimSAS with 12 x SATA 6Gb/s ports Onboard Video Onboard Video Chipset Onboard Video Chipset Aspeed AST2600 Onboard LAN LAN Chipset Intel X710-AT2 LAN Speed 10Gbps Second LAN Chipset Intel I210-AT Second LAN Speed 10/100/1000Mbps Max LAN Speed 10Gbps Rear Panel Ports Back I/O Ports 2 x USB 3.01 x VGA1 x COM (RJ45 type)4 x RJ451 x MLAN1 x ID button with LED Onboard Ports Other Connectors 1 x 24-pin ATX main power connector2 x 8-pin ATX 12V power connectors1 x 6-pin PCIe power connectors3 x SlimSAS connectors2 x 7-pin SATA connectors2 x M.2 slots1 x HDD back plane board header2 x CPU fan headers5 x System fan headers1 x USB 3.0 header1 x TPM header1 x VROC connector1 x Front panel header1 x PMBus connector1 x IPMB connector1 x Clear CMOS jumper1 x BIOS recovery jumper1 x Case open header Dimensions Form Factor Extended ATX Dimensions (W x L) 12″ x 13″ Packaging Package Contents 1 x MD72-HB01 x I/O shield1 x Quick start guide1 x SlimSAS for 4 x SATAIII 6Gb/s cable Additional Information Date First Available March 07, 2022 Customer Reviews of the GIGABYTE MD72-HB2 There are no reviews yet. Do you own this product? write a review
